Technical Specifications of EDZ300/6
| Datasheet |  EDZ300/6 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminal Blocks - Wire to Board |
|---|
| Manufacturer | On Shore Technology Inc. |
|---|
| Series | EDZ300 |
|---|
| Packaging | Bulk |
|---|
| Number of Levels | 1 |
|---|
| Positions Per Level | 6 |
|---|
| Pitch | 0.200" (5.08mm) |
|---|
| Mating Orientation | 45° (135°) Angle with Board |
|---|
| Current | 15A |
|---|
| Voltage | 300V |
|---|
| Wire Gauge | 12-22 AWG |
|---|
| Mounting Type | Through Hole |
|---|
| Wire Termination | Screw - Rising Cage Clamp |
|---|
| Features | Interlocking (Side) |
|---|
| Color | Gray |
|---|
| Operating Temperature | -30°C ~ 105°C |
|---|
| Housing Material | Polyamide (PA), Nylon |
|---|
| Contact Material - Plating | Brass |
|---|
| Clamp Material - Plating | Copper |
|---|
| Screw Material - Plating | - |
|---|
| Torque - Screw | 0.5 Nm (4.4 Lb-In) |
|---|
| Screw Thread | M2.6 |
|---|
We can supply On Shore Technology Inc. part# EDZ300/6. Use the request quote form to request EDZ300/6 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number EDZ300/6. The price and lead time for EDZ300/6 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# EDZ300/6. We look forward to doing business with you.
