Technical Specifications of EM244503
| Datasheet |  EM244503 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminal Blocks - Wire to Board |
|---|
| Manufacturer | Eaton |
|---|
| Series | Euro-Mag EM2445 |
|---|
| Packaging | Bulk |
|---|
| Number of Levels | 2 |
|---|
| Positions Per Level | 3 |
|---|
| Pitch | 0.197" (5.00mm) |
|---|
| Mating Orientation | Horizontal with Board |
|---|
| Current | 16A |
|---|
| Voltage | 300V |
|---|
| Wire Gauge | 14-24 AWG |
|---|
| Mounting Type | Through Hole |
|---|
| Wire Termination | Screw - Rising Cage Clamp |
|---|
| Features | Interlocking (Side) |
|---|
| Color | - |
|---|
| Operating Temperature | -40°C ~ 105°C |
|---|
| Housing Material | Thermoplastic |
|---|
| Contact Material - Plating | Brass - Tin Plated |
|---|
| Clamp Material - Plating | - |
|---|
| Screw Material - Plating | Steel - Nickel Plated |
|---|
| Torque - Screw | 0.56 Nm (5.0 Lb-In) |
|---|
| Screw Thread | M2 |
|---|
We can supply Eaton part# EM244503. Use the request quote form to request EM244503 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number EM244503. The price and lead time for EM244503 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# EM244503. We look forward to doing business with you.
