0433-0-15-01-03-27-04-0
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0433-0-15-01-03-27-04-0 |
|---|---|
| Manufacturer | Mill-Max Manufacturing Corp. |
| Description | Pin Receptacle Connector 0.040" ~ 0.060" (1.02mm ~ 1.52mm) Standard Tail Press-Fit |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 0433-0-15-01-03-27-04-0 Price |  |
Technical Specifications of 0433-0-15-01-03-27-04-0
| Datasheet |  0433-0-15-01-03-27-04-0 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminals - PC Pin Receptacles, Socket Connectors |
| Manufacturer | Mill-Max Manufacturing Corp. |
| Series | 0433 |
| Packaging | Bulk |
| Tail Type | Standard Tail |
| Termination | Press-Fit |
| Length - Overall | 0.390" (9.91mm) |
| Accepts Pin Diameter | 0.040" ~ 0.060" (1.02mm ~ 1.52mm) |
| Mounting Hole Diameter | 0.106" (2.69mm) |
| Pin Hole Diameter | 0.078" (1.98mm) |
| Flange Diameter | 0.120" (3.05mm) |
| Tail Diameter | 0.040" (1.02mm) |
| Socket Depth | 0.205" (5.21mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Features | - |
| Operating Temperature | -55°C ~ 125°C |
| Board Thickness | - |
| Insertion Force | - |
