0616-0-18-01-07-01-10-0
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0616-0-18-01-07-01-10-0 |
|---|---|
| Manufacturer | Mill-Max Manufacturing Corp. |
| Description | Pin Receptacle Connector 0.065" ~ 0.082" (1.65mm ~ 2.08mm) Solder Cup Press-Fit |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 0616-0-18-01-07-01-10-0 Price |  |
Technical Specifications of 0616-0-18-01-07-01-10-0
| Datasheet |  0616-0-18-01-07-01-10-0 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminals - PC Pin Receptacles, Socket Connectors |
| Manufacturer | Mill-Max Manufacturing Corp. |
| Series | 0616 |
| Packaging | Bulk |
| Tail Type | Solder Cup |
| Termination | Press-Fit |
| Length - Overall | 0.455" (11.56mm) |
| Accepts Pin Diameter | 0.065" ~ 0.082" (1.65mm ~ 2.08mm) |
| Mounting Hole Diameter | 0.144" (3.66mm) |
| Pin Hole Diameter | 0.107" (2.72mm) |
| Flange Diameter | 0.157" (3.99mm) |
| Tail Diameter | - |
| Socket Depth | 0.220" (5.59mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 200μin (5.08μm) |
| Features | - |
| Operating Temperature | -55°C ~ 125°C |
| Board Thickness | - |
| Insertion Force | - |
