0579-0-15-01-11-27-10-0
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0579-0-15-01-11-27-10-0 |
|---|---|
| Manufacturer | Mill-Max Manufacturing Corp. |
| Description | Pin Receptacle Connector 0.015" ~ 0.020" (0.38mm ~ 0.51mm) No Tail Press-Fit |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 0579-0-15-01-11-27-10-0 Price |  |
Technical Specifications of 0579-0-15-01-11-27-10-0
| Datasheet |  0579-0-15-01-11-27-10-0 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminals - PC Pin Receptacles, Socket Connectors |
| Manufacturer | Mill-Max Manufacturing Corp. |
| Series | 0579 |
| Packaging | Bulk |
| Tail Type | No Tail |
| Termination | Press-Fit |
| Length - Overall | 0.225" (5.72mm) |
| Accepts Pin Diameter | 0.015" ~ 0.020" (0.38mm ~ 0.51mm) |
| Mounting Hole Diameter | 0.040" (1.02mm) |
| Pin Hole Diameter | 0.031" (0.79mm) |
| Flange Diameter | 0.055" (1.40mm) |
| Tail Diameter | - |
| Socket Depth | 0.195" (4.95mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Features | - |
| Operating Temperature | -55°C ~ 125°C |
| Board Thickness | - |
| Insertion Force | - |
