0280-3-17-01-06-01-02-0
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0280-3-17-01-06-01-02-0 |
|---|---|
| Manufacturer | Mill-Max Manufacturing Corp. |
| Description | Pin Receptacle Connector 0.022" ~ 0.032" (0.56mm ~ 0.81mm) Wire Wrap Press-Fit |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 0280-3-17-01-06-01-02-0 Price |  |
Technical Specifications of 0280-3-17-01-06-01-02-0
| Datasheet |  0280-3-17-01-06-01-02-0 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminals - PC Pin Receptacles, Socket Connectors |
| Manufacturer | Mill-Max Manufacturing Corp. |
| Series | 0280 |
| Packaging | Bulk |
| Tail Type | Wire Wrap |
| Termination | Press-Fit |
| Length - Overall | 0.802" (20.37mm) |
| Accepts Pin Diameter | 0.022" ~ 0.032" (0.56mm ~ 0.81mm) |
| Mounting Hole Diameter | 0.081" (2.06mm) |
| Pin Hole Diameter | 0.051" (1.30mm) |
| Flange Diameter | 0.087" (2.21mm) |
| Tail Diameter | 0.025" (0.64mm) Square |
| Socket Depth | 0.225" (5.72mm) |
| Contact Material | Beryllium Copper |
| Contact Finish | Tin-Lead |
| Contact Finish Thickness | 200μin (5.08μm) |
| Features | - |
| Operating Temperature | -55°C ~ 125°C |
| Board Thickness | - |
| Insertion Force | - |
