Technical Specifications of PNL-4-C
| Datasheet |  PNL-4-C datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Rectangular Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | Pan-Lug? |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Lug, Grounding |
|---|
| Stud/Tab Size | - |
|---|
| Terminal Style | Single Stud Hole |
|---|
| Tab Thickness | 0.140" (3.56mm) |
|---|
| Length - Overall | 1.250" (31.75mm) |
|---|
| Width - Outer Edges | 0.530" (13.46mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Screw |
|---|
| Wire Gauge | 4-14 AWG |
|---|
| Insulation | Non-Insulated |
|---|
| Features | With Screw |
|---|
| Color | - |
|---|
| Contact Finish | - |
|---|
| Contact Material | Copper Alloy |
|---|
| Diameter - Barrel ID | - |
|---|
| Diameter - Barrel OD | - |
|---|
| Diameter - Ring ID | 0.270" (6.86mm) |
|---|
We can supply Panduit Corp part# PNL-4-C. Use the request quote form to request PNL-4-C pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PNL-4-C. The price and lead time for PNL-4-C depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PNL-4-C. We look forward to doing business with you.
