Technical Specifications of 696781-1
| Datasheet |  696781-1 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Rectangular Connectors |
|---|
| Manufacturer | TE Connectivity AMP Connectors |
|---|
| Series | Ampower |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Rectangular Tongue |
|---|
| Stud/Tab Size | - |
|---|
| Terminal Style | No Stud Hole |
|---|
| Tab Thickness | 0.420" (10.67mm) |
|---|
| Length - Overall | 4.200" (106.68mm) |
|---|
| Width - Outer Edges | 1.340" (34.04mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Wire Gauge | 500 MCM (kcmil) |
|---|
| Insulation | Non-Insulated |
|---|
| Features | - |
|---|
| Color | - |
|---|
| Contact Finish | Tin |
|---|
| Contact Material | Copper |
|---|
| Diameter - Barrel ID | 1.030" (26.16mm) |
|---|
| Diameter - Barrel OD | 1.320" (33.53mm) |
|---|
| Diameter - Ring ID | - |
|---|
We can supply TE Connectivity AMP Connectors part# 696781-1. Use the request quote form to request 696781-1 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 696781-1. The price and lead time for 696781-1 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 696781-1. We look forward to doing business with you.
