Technical Specifications of PN18-14F-C
| Datasheet |  PN18-14F-C datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Spade Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | Pan-Term? |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Standard |
|---|
| Stud/Tab Size | 1/4 Stud |
|---|
| Width - Outer Edges | 0.440" (11.18mm) |
|---|
| Length - Overall | 1.030" (26.16mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Wire Gauge | 18-22 AWG |
|---|
| Insulation | Insulated |
|---|
| Features | Butted Seam |
|---|
| Color | Red |
|---|
| Contact Finish | Tin |
|---|
| Contact Material | Copper |
|---|
| Insulation Diameter | 0.145" (3.68mm) |
|---|
| Material - Insulation | Polyamide (PA), Nylon |
|---|
| Length - Ring Center to Termination | - |
|---|
| Length - Termination | - |
|---|
| Tongue Inside Opening | 0.270" (6.86mm) |
|---|
We can supply Panduit Corp part# PN18-14F-C. Use the request quote form to request PN18-14F-C pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PN18-14F-C. The price and lead time for PN18-14F-C depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PN18-14F-C. We look forward to doing business with you.
