Technical Specifications of 19099-0003
| Datasheet |  19099-0003 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Spade Connectors |
|---|
| Manufacturer | Molex Connector Corporation |
|---|
| Series | InsulKrimp? |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Spring, Snap |
|---|
| Stud/Tab Size | 8 Stud |
|---|
| Width - Outer Edges | 0.290" (7.37mm) |
|---|
| Length - Overall | 0.880" (22.35mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Wire Gauge | 18-22 AWG |
|---|
| Insulation | Insulated |
|---|
| Features | - |
|---|
| Color | Red |
|---|
| Contact Finish | Electro-Tin |
|---|
| Contact Material | Copper |
|---|
| Insulation Diameter | 0.145" (3.68mm) |
|---|
| Material - Insulation | Poly-Vinyl Chloride (PVC) |
|---|
| Length - Ring Center to Termination | 0.235" (5.97mm) |
|---|
| Length - Termination | 0.405" (10.29mm) |
|---|
| Tongue Inside Opening | 0.137" (3.48mm) |
|---|
We can supply Molex Connector Corporation part# 19099-0003. Use the request quote form to request 19099-0003 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 19099-0003. The price and lead time for 19099-0003 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 19099-0003. We look forward to doing business with you.
