Technical Specifications of BAT54BRW-7-F
| Datasheet |  BAT54BRW-7-F datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Arrays |
|---|
| Manufacturer | Diodes Incorporated |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Configuration | 2 Pair Series Connection |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 30V |
|---|
| Current - Average Rectified (Io) (per Diode) | 200mA (DC) |
|---|
| Voltage - Forward (Vf) (Max) @ If | 1V @ 100mA |
|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
|---|
| Reverse Recovery Time (trr) | 5ns |
|---|
| Current - Reverse Leakage @ Vr | 2μA @ 25V |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
|---|
| Supplier Device Package | SOT-363 |
|---|
We can supply Diodes Incorporated part# BAT54BRW-7-F. Use the request quote form to request BAT54BRW-7-F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number BAT54BRW-7-F. The price and lead time for BAT54BRW-7-F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# BAT54BRW-7-F. We look forward to doing business with you.
