Technical Specifications of SB80W06T-TL-H
| Datasheet |  SB80W06T-TL-H datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Arrays |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Configuration | 1 Pair Common Cathode |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 60V |
|---|
| Current - Average Rectified (Io) (per Diode) | 4A |
|---|
| Voltage - Forward (Vf) (Max) @ If | 600mV @ 3A |
|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Current - Reverse Leakage @ Vr | 100μA @ 30V |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|---|
| Supplier Device Package | TP-FA |
|---|
We can supply ON Semiconductor part# SB80W06T-TL-H. Use the request quote form to request SB80W06T-TL-H pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SB80W06T-TL-H. The price and lead time for SB80W06T-TL-H depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SB80W06T-TL-H. We look forward to doing business with you.
