Technical Specifications of BAW56W-7-F
| Datasheet |  BAW56W-7-F datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Arrays |
|---|
| Manufacturer | Diodes Incorporated |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Configuration | 1 Pair Common Anode |
|---|
| Diode Type | Standard |
|---|
| Voltage - DC Reverse (Vr) (Max) | 75V |
|---|
| Current - Average Rectified (Io) (per Diode) | 150mA |
|---|
| Voltage - Forward (Vf) (Max) @ If | 1.25V @ 150mA |
|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
|---|
| Reverse Recovery Time (trr) | 4ns |
|---|
| Current - Reverse Leakage @ Vr | 2.5μA @ 75V |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SC-70, SOT-323 |
|---|
| Supplier Device Package | SOT-323 |
|---|
We can supply Diodes Incorporated part# BAW56W-7-F. Use the request quote form to request BAW56W-7-F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number BAW56W-7-F. The price and lead time for BAW56W-7-F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# BAW56W-7-F. We look forward to doing business with you.
