Technical Specifications of DB2S20500L
| Datasheet |  DB2S20500L datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | Panasonic Electronic Components |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 15V |
|---|
| Current - Average Rectified (Io) | 200mA |
|---|
| Voltage - Forward (Vf) (Max) @ If | 390mV @ 200mA |
|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
|---|
| Reverse Recovery Time (trr) | 2.2ns |
|---|
| Current - Reverse Leakage @ Vr | 50μA @ 6V |
|---|
| Capacitance @ Vr, F | 6.1pF @ 10V, 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SC-79, SOD-523 |
|---|
| Supplier Device Package | SSMini2-F5-B |
|---|
| Operating Temperature - Junction | 125°C (Max) |
|---|
We can supply Panasonic Electronic Components part# DB2S20500L. Use the request quote form to request DB2S20500L pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number DB2S20500L. The price and lead time for DB2S20500L depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# DB2S20500L. We look forward to doing business with you.
