Technical Specifications of TCR22-6RP
| Datasheet |  TCR22-6RP datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Thyristors - SCRs |
|---|
| Manufacturer | Littelfuse Inc. |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Voltage - Off State | 400V |
|---|
| Voltage - Gate Trigger (Vgt) (Max) | 800mV |
|---|
| Current - Gate Trigger (Igt) (Max) | 200μA |
|---|
| Voltage - On State (Vtm) (Max) | 1.5V |
|---|
| Current - On State (It (AV)) (Max) | 950mA |
|---|
| Current - On State (It (RMS)) (Max) | 1.5A |
|---|
| Current - Hold (Ih) (Max) | 5mA |
|---|
| Current - Off State (Max) | 1μA |
|---|
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 16A, 20A |
|---|
| SCR Type | Sensitive Gate |
|---|
| Operating Temperature | -40°C ~ 110°C |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) (Formed Leads) |
|---|
| Supplier Device Package | TO-92 |
|---|
We can supply Littelfuse Inc. part# TCR22-6RP. Use the request quote form to request TCR22-6RP pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TCR22-6RP. The price and lead time for TCR22-6RP depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TCR22-6RP. We look forward to doing business with you.
