Technical Specifications of VS-25TTS16SPBF
| Datasheet |  VS-25TTS16SPBF datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Thyristors - SCRs |
|---|
| Manufacturer | Vishay Semiconductor Diodes Division |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| Voltage - Off State | 1600V |
|---|
| Voltage - Gate Trigger (Vgt) (Max) | 2V |
|---|
| Current - Gate Trigger (Igt) (Max) | 45mA |
|---|
| Voltage - On State (Vtm) (Max) | 1.25V |
|---|
| Current - On State (It (AV)) (Max) | 16A |
|---|
| Current - On State (It (RMS)) (Max) | 25A |
|---|
| Current - Hold (Ih) (Max) | 150mA |
|---|
| Current - Off State (Max) | 500μA |
|---|
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 300A @ 50Hz |
|---|
| SCR Type | Standard Recovery |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Supplier Device Package | TO-263AB (D2PAK) |
|---|
We can supply Vishay Semiconductor Diodes Division part# VS-25TTS16SPBF. Use the request quote form to request VS-25TTS16SPBF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number VS-25TTS16SPBF. The price and lead time for VS-25TTS16SPBF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# VS-25TTS16SPBF. We look forward to doing business with you.
