Technical Specifications of MCR100-6ZL1G
| Datasheet |  MCR100-6ZL1G datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Thyristors - SCRs |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Box (TB) |
|---|
| Voltage - Off State | 400V |
|---|
| Voltage - Gate Trigger (Vgt) (Max) | 800mV |
|---|
| Current - Gate Trigger (Igt) (Max) | 200μA |
|---|
| Voltage - On State (Vtm) (Max) | 1.7V |
|---|
| Current - On State (It (AV)) (Max) | - |
|---|
| Current - On State (It (RMS)) (Max) | 800mA |
|---|
| Current - Hold (Ih) (Max) | 5mA |
|---|
| Current - Off State (Max) | 10μA |
|---|
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 10A @ 60Hz |
|---|
| SCR Type | Sensitive Gate |
|---|
| Operating Temperature | -40°C ~ 110°C |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) (Formed Leads) |
|---|
| Supplier Device Package | TO-92-3 |
|---|
We can supply ON Semiconductor part# MCR100-6ZL1G. Use the request quote form to request MCR100-6ZL1G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MCR100-6ZL1G. The price and lead time for MCR100-6ZL1G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MCR100-6ZL1G. We look forward to doing business with you.
