DMG264120R
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DMG264120R |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Description | TRANS NPN/PNP PREBIAS 0.3W MINI6 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DMG264120R Price |  |
Technical Specifications of DMG264120R
| Datasheet |  DMG264120R datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Arrays, Pre-Biased |
| Manufacturer | Panasonic Electronic Components |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | 1 NPN, 1 PNP - Pre-Biased (Dual) |
| Current - Collector (Ic) (Max) | 500mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 4.7k |
| Resistor - Emitter Base (R2) (Ohms) | 4.7k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 100mA, 10V |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 5mA, 100mA |
| Current - Collector Cutoff (Max) | 1μA |
| Frequency - Transition | - |
| Power - Max | 300mW |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 |
| Supplier Device Package | Mini6-G4-B |
