NSBC113EPDXV6T1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | NSBC113EPDXV6T1 |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | TRANS PREBIAS NPN/PNP SOT563 |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| NSBC113EPDXV6T1 Price |  |
Technical Specifications of NSBC113EPDXV6T1
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Transistors - Bipolar (BJT) - Arrays, Pre-Biased |
| Manufacturer | ON Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | 1 NPN, 1 PNP - Pre-Biased (Dual) |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 1k |
| Resistor - Emitter Base (R2) (Ohms) | 1k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 3 @ 5mA, 10V |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 5mA, 10mA |
| Current - Collector Cutoff (Max) | 500nA |
| Frequency - Transition | - |
| Power - Max | 500mW |
| Mounting Type | Surface Mount |
| Package / Case | SOT-563, SOT-666 |
| Supplier Device Package | SOT-563 |
