SMUN5311DW1T3G
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SMUN5311DW1T3G |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | TRANS NPN/PNP PREBIAS SOT363 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SMUN5311DW1T3G Price |  |
Technical Specifications of SMUN5311DW1T3G
| Datasheet |  SMUN5311DW1T3G datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Arrays, Pre-Biased |
| Manufacturer | ON Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | 1 NPN, 1 PNP - Pre-Biased (Dual) |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 10k |
| Resistor - Emitter Base (R2) (Ohms) | 10k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 35 @ 5mA, 10V |
| Vce Saturation (Max) @ Ib, Ic | 250mV @ 300μA, 10mA |
| Current - Collector Cutoff (Max) | 500nA |
| Frequency - Transition | - |
| Power - Max | 187mW |
| Mounting Type | Surface Mount |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | SOT-363 |
