RN2310,LF
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | RN2310,LF |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | TRANS PREBIAS PNP 0.1W USM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| RN2310,LF Price |  |
Technical Specifications of RN2310,LF
| Datasheet |  RN2310,LF datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Single, Pre-Biased |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Digi-Reel? |
| Transistor Type | PNP - Pre-Biased |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 4.7k |
| Resistor - Emitter Base (R2) (Ohms) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 120 @ 1mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 250μA, 5mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| Frequency - Transition | 200MHz |
| Power - Max | 100mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-70, SOT-323 |
| Supplier Device Package | USM |
