PDTB123TT,215
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | PDTB123TT,215 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | TRANS PREBIAS PNP 250MW TO236AB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| PDTB123TT,215 Price |  |
Technical Specifications of PDTB123TT,215
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Transistors - Bipolar (BJT) - Single, Pre-Biased |
| Manufacturer | NXP Semiconductors |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | PNP - Pre-Biased |
| Current - Collector (Ic) (Max) | 500mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 2.2k |
| Resistor - Emitter Base (R2) (Ohms) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 50mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 2.5mA, 50mA |
| Current - Collector Cutoff (Max) | 500nA |
| Frequency - Transition | - |
| Power - Max | 250mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23 (TO-236AB) |
