DTD513ZETL
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DTD513ZETL |
|---|---|
| Manufacturer | Rohm Semiconductor |
| Description | TRANS PREBIAS NPN 150MW EMT3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DTD513ZETL Price |  |
Technical Specifications of DTD513ZETL
| Datasheet |  DTD513ZETL datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Single, Pre-Biased |
| Manufacturer | Rohm Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | NPN - Pre-Biased |
| Current - Collector (Ic) (Max) | 500mA |
| Voltage - Collector Emitter Breakdown (Max) | 12V |
| Resistor - Base (R1) (Ohms) | 1k |
| Resistor - Emitter Base (R2) (Ohms) | 10k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 140 @ 100mA, 2V |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 5mA, 100mA |
| Current - Collector Cutoff (Max) | 500nA |
| Frequency - Transition | 260MHz |
| Power - Max | 150mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-75, SOT-416 |
| Supplier Device Package | EMT3 |
