PDTC143ET,215
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | PDTC143ET,215 |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | TRANS PREBIAS NPN 250MW TO236AB |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| PDTC143ET,215 Price |  |
Technical Specifications of PDTC143ET,215
| Datasheet |  PDTC143ET,215 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Single, Pre-Biased |
| Manufacturer | NXP Semiconductors |
| Series | - |
| Packaging | Cut Tape (CT) |
| Transistor Type | NPN - Pre-Biased |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 4.7k |
| Resistor - Emitter Base (R2) (Ohms) | 4.7k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 30 @ 10mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 150mV @ 500μA, 10mA |
| Current - Collector Cutoff (Max) | 1μA |
| Frequency - Transition | - |
| Power - Max | 250mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23 (TO-236AB) |
