DRC5643T0L
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | DRC5643T0L |
|---|---|
| Manufacturer | Panasonic Electronic Components |
| Description | TRANS PREBIAS NPN 150MW SMINI3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| DRC5643T0L Price |  |
Technical Specifications of DRC5643T0L
| Datasheet |  DRC5643T0L datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Single, Pre-Biased |
| Manufacturer | Panasonic Electronic Components |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | NPN - Pre-Biased |
| Current - Collector (Ic) (Max) | 600mA |
| Voltage - Collector Emitter Breakdown (Max) | 20V |
| Resistor - Base (R1) (Ohms) | 4.7k |
| Resistor - Emitter Base (R2) (Ohms) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 50mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 80mV @ 2.5mA, 50mA |
| Current - Collector Cutoff (Max) | 1μA (ICBO) |
| Frequency - Transition | - |
| Power - Max | 150mW |
| Mounting Type | Surface Mount |
| Package / Case | SC-85 |
| Supplier Device Package | SMini3-F2-B |
