Technical Specifications of IPG20N06S3L-23
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | OptiMOS? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | 2 N-Channel (Dual) |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 55V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 20A |
|---|
| Rds On (Max) @ Id, Vgs | 23 mOhm @ 16A, 10V |
|---|
| Vgs(th) (Max) @ Id | 2.2V @ 20μA |
|---|
| Gate Charge (Qg) @ Vgs | 42nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 2950pF @ 25V |
|---|
| Power - Max | 45W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-PowerVDFN |
|---|
| Supplier Device Package | PG-TDSON-8-4 (5.15x6.15) |
|---|
We can supply Infineon Technologies part# IPG20N06S3L-23. Use the request quote form to request IPG20N06S3L-23 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IPG20N06S3L-23. The price and lead time for IPG20N06S3L-23 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IPG20N06S3L-23. We look forward to doing business with you.
