TPCF8402(TE85L,F,M
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TPCF8402(TE85L,F,M |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N/P-CH 30V 4A/3.2A VS-8 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TPCF8402(TE85L,F,M Price |  |
Technical Specifications of TPCF8402(TE85L,F,M
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| FET Type | N and P-Channel |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 4A, 3.2A |
| Rds On (Max) @ Id, Vgs | 50 mOhm @ 2A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 1mA |
| Gate Charge (Qg) @ Vgs | 10nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 470pF @ 10V |
| Power - Max | 330mW |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Flat Lead |
| Supplier Device Package | VS-8 (2.9x1.9) |
