GMM3X120-0075X2-SMDSAM
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | GMM3X120-0075X2-SMDSAM |
|---|---|
| Manufacturer | IXYS |
| Description | MOSFET 6N-CH 75V 110A 24-SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| GMM3X120-0075X2-SMDSAM Price |  |
Technical Specifications of GMM3X120-0075X2-SMDSAM
| Datasheet |  GMM3X120-0075X2-SMDSAM datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Arrays |
| Manufacturer | IXYS |
| Series | - |
| Packaging | Tube |
| FET Type | 6 N-Channel (3-Phase Bridge) |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 75V |
| Current - Continuous Drain (Id) @ 25°C | 110A |
| Rds On (Max) @ Id, Vgs | - |
| Vgs(th) (Max) @ Id | 4V @ 1mA |
| Gate Charge (Qg) @ Vgs | 115nC @ 10V |
| Input Capacitance (Ciss) @ Vds | - |
| Power - Max | - |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 24-SMD, Gull Wing |
| Supplier Device Package | 24-SMD |
