APTML1002U60R020T3AG
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | APTML1002U60R020T3AG |
|---|---|
| Manufacturer | Microsemi Corporation |
| Description | MOSFET 2N-CH 1000V 20A SP3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| APTML1002U60R020T3AG Price |  |
Technical Specifications of APTML1002U60R020T3AG
| Datasheet |  APTML1002U60R020T3AG datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Arrays |
| Manufacturer | Microsemi Corporation |
| Series | - |
| Packaging | Bulk |
| FET Type | 2 N-Channel (Dual) |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 1000V (1kV) |
| Current - Continuous Drain (Id) @ 25°C | 20A |
| Rds On (Max) @ Id, Vgs | 720 mOhm @ 10A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 2.5mA |
| Gate Charge (Qg) @ Vgs | - |
| Input Capacitance (Ciss) @ Vds | 6000pF @ 25V |
| Power - Max | 520W |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Chassis Mount |
| Package / Case | SP3 |
| Supplier Device Package | SP3 |
