IPG20N06S2L65AATMA1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | IPG20N06S2L65AATMA1 |
|---|---|
| Manufacturer | Infineon Technologies |
| Description | MOSFET 2N-CH 8TDSON |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| IPG20N06S2L65AATMA1 Price |  |
Technical Specifications of IPG20N06S2L65AATMA1
| Datasheet |  IPG20N06S2L65AATMA1 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Arrays |
| Manufacturer | Infineon Technologies |
| Series | Automotive, AEC-Q101, OptiMOS? |
| Packaging | Tape & Reel (TR) |
| FET Type | 2 N-Channel (Dual) |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 55V |
| Current - Continuous Drain (Id) @ 25°C | 20A |
| Rds On (Max) @ Id, Vgs | 65 mOhm @ 15A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 14μA |
| Gate Charge (Qg) @ Vgs | 12nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 410pF @ 25V |
| Power - Max | 43W |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerVDFN |
| Supplier Device Package | PG-TDSON-8-10 |
