Technical Specifications of APTC60HM24T3G
| Datasheet |  APTC60HM24T3G datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Arrays |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | CoolMOS? |
|---|
| Packaging | Tray |
|---|
| FET Type | 4 N-Channel (H-Bridge) |
|---|
| FET Feature | Super Junction |
|---|
| Drain to Source Voltage (Vdss) | 600V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 95A |
|---|
| Rds On (Max) @ Id, Vgs | 24 mOhm @ 47.5A, 10V |
|---|
| Vgs(th) (Max) @ Id | 3.9V @ 5mA |
|---|
| Gate Charge (Qg) @ Vgs | 300nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 14400pF @ 25V |
|---|
| Power - Max | 462W |
|---|
| Operating Temperature | -40°C ~ 150°C (TJ) |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | SP3 |
|---|
| Supplier Device Package | SP3 |
|---|
We can supply Microsemi Corporation part# APTC60HM24T3G. Use the request quote form to request APTC60HM24T3G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APTC60HM24T3G. The price and lead time for APTC60HM24T3G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APTC60HM24T3G. We look forward to doing business with you.
