Technical Specifications of DMN61D8LQ-13
| Datasheet |  DMN61D8LQ-13 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Diodes Incorporated |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 60V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 470mA (Ta) |
|---|
| Rds On (Max) @ Id, Vgs | 1.8 Ohm @ 150mA, 5V |
|---|
| Vgs(th) (Max) @ Id | 2V @ 1mA |
|---|
| Gate Charge (Qg) @ Vgs | 0.74nC @ 5V |
|---|
| Input Capacitance (Ciss) @ Vds | 12.9pF @ 12V |
|---|
| Power - Max | 390mW |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
|---|
| Supplier Device Package | SOT-23 |
|---|
We can supply Diodes Incorporated part# DMN61D8LQ-13. Use the request quote form to request DMN61D8LQ-13 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number DMN61D8LQ-13. The price and lead time for DMN61D8LQ-13 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# DMN61D8LQ-13. We look forward to doing business with you.
