SSM3K302T(TE85L,F)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SSM3K302T(TE85L,F) |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N-CH 30V 3A TSM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SSM3K302T(TE85L,F) Price |  |
Technical Specifications of SSM3K302T(TE85L,F)
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Logic Level Gate, 1.8V Drive |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 3A (Ta) |
| Rds On (Max) @ Id, Vgs | 71 mOhm @ 2A, 4V |
| Vgs(th) (Max) @ Id | - |
| Gate Charge (Qg) @ Vgs | 4.3nC @ 4V |
| Input Capacitance (Ciss) @ Vds | 270pF @ 10V |
| Power - Max | 700mW |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | TSM |
