TPCA8006-H(TE12L,Q
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TPCA8006-H(TE12L,Q |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N-CH 100V 18A 8-SOPA |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TPCA8006-H(TE12L,Q Price |  |
Technical Specifications of TPCA8006-H(TE12L,Q
| Datasheet |  TPCA8006-H(TE12L,Q datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Digi-Reel? |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 100V |
| Current - Continuous Drain (Id) @ 25°C | 18A (Ta) |
| Rds On (Max) @ Id, Vgs | 67 mOhm @ 9A, 10V |
| Vgs(th) (Max) @ Id | 5V @ 1mA |
| Gate Charge (Qg) @ Vgs | 12nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 780pF @ 10V |
| Power - Max | 45W |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerVDFN |
| Supplier Device Package | 8-SOP Advance |
