Technical Specifications of JANTXV2N6798U
| Datasheet |  JANTXV2N6798U datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Microsemi IRE Division |
|---|
| Series | Military, MIL-PRF-19500/557 |
|---|
| Packaging | Bulk |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 200V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 5.5A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 420 mOhm @ 5.5A, 10V |
|---|
| Vgs(th) (Max) @ Id | 4V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 42.07nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | - |
|---|
| Power - Max | 800mW |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 18-BQFN Exposed Pad |
|---|
| Supplier Device Package | 18-ULCC (9.14x7.49) |
|---|
We can supply Microsemi IRE Division part# JANTXV2N6798U. Use the request quote form to request JANTXV2N6798U pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number JANTXV2N6798U. The price and lead time for JANTXV2N6798U depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# JANTXV2N6798U. We look forward to doing business with you.
