Technical Specifications of PSMN020-30MLCX
| Datasheet |  PSMN020-30MLCX datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | NXP Semiconductors |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate, 4.5V Drive |
|---|
| Drain to Source Voltage (Vdss) | 30V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 31.8A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 18.1 mOhm @ 5A, 10V |
|---|
| Vgs(th) (Max) @ Id | 1.95V @ 1mA |
|---|
| Gate Charge (Qg) @ Vgs | 9.5nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 430pF @ 15V |
|---|
| Power - Max | 33W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SOT-1210, 8-LFPAK33 (5-Lead) |
|---|
| Supplier Device Package | LFPAK33 |
|---|
We can supply NXP Semiconductors part# PSMN020-30MLCX. Use the request quote form to request PSMN020-30MLCX pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PSMN020-30MLCX. The price and lead time for PSMN020-30MLCX depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PSMN020-30MLCX. We look forward to doing business with you.
