Technical Specifications of NTMFS4C09NT1G-001
| Datasheet |  NTMFS4C09NT1G-001 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 30V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 9A (Ta), 52A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 5.8 mOhm @ 30A, 10V |
|---|
| Vgs(th) (Max) @ Id | 2.1V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 22.2nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 1252pF @ 15V |
|---|
| Power - Max | 760mW |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-PowerTDFN |
|---|
| Supplier Device Package | 5-DFN, 8-SO Flat Lead (5x6) |
|---|
We can supply ON Semiconductor part# NTMFS4C09NT1G-001. Use the request quote form to request NTMFS4C09NT1G-001 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number NTMFS4C09NT1G-001. The price and lead time for NTMFS4C09NT1G-001 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# NTMFS4C09NT1G-001. We look forward to doing business with you.
