Technical Specifications of FQPF5N15
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | QFET? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 150V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 4.2A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 800 mOhm @ 2.1A, 10V |
|---|
| Vgs(th) (Max) @ Id | 4V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 7nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 230pF @ 25V |
|---|
| Power - Max | 32W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-220-3 Full Pack |
|---|
| Supplier Device Package | TO-220F |
|---|
We can supply Fairchild Semiconductor part# FQPF5N15. Use the request quote form to request FQPF5N15 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FQPF5N15. The price and lead time for FQPF5N15 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FQPF5N15. We look forward to doing business with you.
