Technical Specifications of IRL3303S
| Datasheet |  IRL3303S datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | HEXFET? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 30V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 38A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 26 mOhm @ 20A, 10V |
|---|
| Vgs(th) (Max) @ Id | 1V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 26nC @ 4.5V |
|---|
| Input Capacitance (Ciss) @ Vds | 870pF @ 25V |
|---|
| Power - Max | 3.8W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Supplier Device Package | D2PAK |
|---|
We can supply Infineon Technologies part# IRL3303S. Use the request quote form to request IRL3303S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IRL3303S. The price and lead time for IRL3303S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IRL3303S. We look forward to doing business with you.
