Technical Specifications of STH320N4F6-2
| Datasheet |  STH320N4F6-2 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | STMicroelectronics |
|---|
| Series | DeepGATE?, STripFET? VI |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 40V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 200A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 1.3 mOhm @ 80A, 10V |
|---|
| Vgs(th) (Max) @ Id | 4V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 240nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 13800pF @ 15V |
|---|
| Power - Max | 300W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab) Variant |
|---|
| Supplier Device Package | H2PAK |
|---|
We can supply STMicroelectronics part# STH320N4F6-2. Use the request quote form to request STH320N4F6-2 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number STH320N4F6-2. The price and lead time for STH320N4F6-2 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# STH320N4F6-2. We look forward to doing business with you.
