Technical Specifications of UPA2821T1L-E1-AT
| Datasheet |  UPA2821T1L-E1-AT datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Renesas Electronics America |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate, 4.5V Drive |
|---|
| Drain to Source Voltage (Vdss) | 30V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 26A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 3.8 mOhm @ 26A, 10V |
|---|
| Vgs(th) (Max) @ Id | - |
|---|
| Gate Charge (Qg) @ Vgs | 51nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 2490pF @ 10V |
|---|
| Power - Max | 1.5W |
|---|
| Operating Temperature | 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-PowerWDFN |
|---|
| Supplier Device Package | 8-HWSON (3.3x3.3) |
|---|
We can supply Renesas Electronics America part# UPA2821T1L-E1-AT. Use the request quote form to request UPA2821T1L-E1-AT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number UPA2821T1L-E1-AT. The price and lead time for UPA2821T1L-E1-AT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# UPA2821T1L-E1-AT. We look forward to doing business with you.
