TK40P04M1(T6RSS-Q)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TK40P04M1(T6RSS-Q) |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N-CH 40V 40A 3DP 2-7K1A |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TK40P04M1(T6RSS-Q) Price |  |
Technical Specifications of TK40P04M1(T6RSS-Q)
| Datasheet |  TK40P04M1(T6RSS-Q) datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 40V |
| Current - Continuous Drain (Id) @ 25°C | 40A (Ta) |
| Rds On (Max) @ Id, Vgs | 11 mOhm @ 20A, 10V |
| Vgs(th) (Max) @ Id | 2.3V @ 200μA |
| Gate Charge (Qg) @ Vgs | 29nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 1920pF @ 10V |
| Power - Max | 47W |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Supplier Device Package | DP |
