Technical Specifications of CSD16322Q5C
| Datasheet |  CSD16322Q5C datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Texas Instruments |
|---|
| Series | NexFET? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 25V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 21A (Ta), 97A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 5 mOhm @ 20A, 8V |
|---|
| Vgs(th) (Max) @ Id | 1.4V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 9.7nC @ 4.5V |
|---|
| Input Capacitance (Ciss) @ Vds | 1365pF @ 12.5V |
|---|
| Power - Max | 3.1W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-PowerTDFN |
|---|
| Supplier Device Package | 8-SON |
|---|
We can supply Texas Instruments part# CSD16322Q5C. Use the request quote form to request CSD16322Q5C pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CSD16322Q5C. The price and lead time for CSD16322Q5C depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CSD16322Q5C. We look forward to doing business with you.
