SSM5G10TU(TE85L,F)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SSM5G10TU(TE85L,F) |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET P-CH 20V 1.5A UFV |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SSM5G10TU(TE85L,F) Price |  |
Technical Specifications of SSM5G10TU(TE85L,F)
| Datasheet |  SSM5G10TU(TE85L,F) datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET P-Channel, Metal Oxide |
| FET Feature | Diode (Isolated), Logic Level Gate |
| Drain to Source Voltage (Vdss) | 20V |
| Current - Continuous Drain (Id) @ 25°C | 1.5A (Ta) |
| Rds On (Max) @ Id, Vgs | 213 mOhm @ 1A, 4V |
| Vgs(th) (Max) @ Id | 1V @ 1mA |
| Gate Charge (Qg) @ Vgs | 6.4nC @ 4V |
| Input Capacitance (Ciss) @ Vds | 250pF @ 10V |
| Power - Max | 500mW |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD (5 Leads), Flat Lead |
| Supplier Device Package | UFV |
