BSD314SPEH6327XTSA1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | BSD314SPEH6327XTSA1 |
|---|---|
| Manufacturer | Infineon Technologies |
| Description | MOSFET P-CH 30V 1.5A SOT363 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| BSD314SPEH6327XTSA1 Price |  |
Technical Specifications of BSD314SPEH6327XTSA1
| Datasheet |  BSD314SPEH6327XTSA1 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS? |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET P-Channel, Metal Oxide |
| FET Feature | Logic Level Gate, 4.5V Drive |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 1.5A (Ta) |
| Rds On (Max) @ Id, Vgs | 140 mOhm @ 1.5A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 6.3μA |
| Gate Charge (Qg) @ Vgs | 2.9nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 294pF @ 15V |
| Power - Max | 500mW |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Supplier Device Package | PG-SOT363-6 |
