Technical Specifications of FQB7N80TM_AM002
| Datasheet |  FQB7N80TM_AM002 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | QFET? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 800V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 6.6A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 1.5 Ohm @ 3.3A, 10V |
|---|
| Vgs(th) (Max) @ Id | 5V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 52nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 1850pF @ 25V |
|---|
| Power - Max | 3.13W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Supplier Device Package | D2PAK |
|---|
We can supply Fairchild Semiconductor part# FQB7N80TM_AM002. Use the request quote form to request FQB7N80TM_AM002 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FQB7N80TM_AM002. The price and lead time for FQB7N80TM_AM002 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FQB7N80TM_AM002. We look forward to doing business with you.
