Technical Specifications of IRF530A
| Datasheet |  IRF530A datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 100V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 14A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 110 mOhm @ 7A, 10V |
|---|
| Vgs(th) (Max) @ Id | 4V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 36nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 790pF @ 25V |
|---|
| Power - Max | 55W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-220-3 |
|---|
| Supplier Device Package | TO-220-3 |
|---|
We can supply Fairchild Semiconductor part# IRF530A. Use the request quote form to request IRF530A pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IRF530A. The price and lead time for IRF530A depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IRF530A. We look forward to doing business with you.
