Technical Specifications of IRFR120Z
| Datasheet |  IRFR120Z datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | HEXFET? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 100V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 8.7A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 190 mOhm @ 5.2A, 10V |
|---|
| Vgs(th) (Max) @ Id | 4V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 10nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 310pF @ 25V |
|---|
| Power - Max | 35W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|---|
| Supplier Device Package | D-Pak |
|---|
We can supply Infineon Technologies part# IRFR120Z. Use the request quote form to request IRFR120Z pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IRFR120Z. The price and lead time for IRFR120Z depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IRFR120Z. We look forward to doing business with you.
