IPP45N06S4L08AKSA2
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | IPP45N06S4L08AKSA2 |
|---|---|
| Manufacturer | Infineon Technologies |
| Description | MOSFET N-CH 60V 45A PG-TO220-3 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| IPP45N06S4L08AKSA2 Price |  |
Technical Specifications of IPP45N06S4L08AKSA2
| Datasheet |  IPP45N06S4L08AKSA2 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Infineon Technologies |
| Series | Automotive, AEC-Q101, OptiMOS? |
| Packaging | Tube |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 45A (Tc) |
| Rds On (Max) @ Id, Vgs | 8.2 mOhm @ 45A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 35μA |
| Gate Charge (Qg) @ Vgs | 64nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 4780pF @ 25V |
| Power - Max | 71W |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | PG-TO220-3-1 |
