Technical Specifications of CSD18534KCS
| Datasheet |  CSD18534KCS datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Texas Instruments |
|---|
| Series | NexFET? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 60V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 45A (Ta), 100A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 9.5 mOhm @ 40A, 10V |
|---|
| Vgs(th) (Max) @ Id | 2.3V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 24nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 1880pF @ 30V |
|---|
| Power - Max | 107W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-220-3 |
|---|
| Supplier Device Package | TO-220-3 |
|---|
We can supply Texas Instruments part# CSD18534KCS. Use the request quote form to request CSD18534KCS pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CSD18534KCS. The price and lead time for CSD18534KCS depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CSD18534KCS. We look forward to doing business with you.
